RIGOL DS1052E DS 1052E 2 Channel Digital Oscilloscope 50MHz DSO 1GSa/S
  50 MHz    Single Channel: 1M; Double Channels: 500K  Channels   2  Real-time sample rate   Single Channel: 1 GSa/s; Double Channels: 500MSa/s  equivalent sample rate   10 GSa/s    1.2 ns  Input Impedance   1 MΩ || 15 pF,50 Ω  Sec/div Range   2 ns/div - 50 s/div  Lissajous Figures     50 MHz  phase difference   ± 3°  Trigger Modes   Edge, Pulse, Video, Slope, Delay  Trigger Source   CH1,CH2,Ext,Ext/5,AC Line  Vertical Sensitivity   2 mV/div -10 V/div  Vertical Resolution   8bit  Input coupling   DC, AC, GND  Input Max voltage   300 V (DC + AC Vpp)  Scroll Range   500 ms/div - 50 s/div  Cursor measure   Manual, Track, Auto  Math   +,-,×,FFT  Storage   Built-in: 10 groups waveforms, 10 groups set up ; USB: bitmap memory, CSV storage, wave set up  Interface   USB Device,USB Host,RS-232,P/F Out (Isolated)    64K TFT Color LCD (320 x 234)    Multilingual User Interface  Power Source Voltage   100-240V AC/ 50W Max  Size   303mm×154mm×133mm(L×H×W)  Weight   Approximately 2.4 kg

• 1Mpts long Memory Depth
• 50 MHz Bandwidths
• Ultra compact design: 303mm x 154mm x 133mm (WxHxD)
• 64 k TFT color LCD, bright and vivid waveform display
• Advanced trigger modes: Edge, Video, Pulse Width, Slope, Alternate
• Adjustable bigger sensitivity: Effactively filter noise from bigger signal and avoid false trigger
• 20 automatic measurements
• Cursor measurements: Manual, Track and Auto Measure modes
• 10 waveforms, 10 setups, BMP and CSV storage
• Math functions:+, -, x, FFT, Invert
• Special digital filter and waveform recorder
• Built-in hardware frequency counter
• Standard interface: USB Device, USB Host, RS-232
• Standard configuration: PassIFail test, effectively avoid electromagnetic interference by using photoelectricity-isolation
• Multi-language user interface, built-in help system
• Direct print to PictBridge compatible printers via USB Device interface.
