You are here: home  > VAS 5054A VW Audi Skoda multi-language diagnostic tool

VAS 5054A VW Audi Skoda multi-language diagnostic tool

Payment Terms: T/T,WU;paypal
Place of Origin: Guangdong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Means of Transport: Air
Packing: full packing
Brand Name: VAS 5054A VW Audi Skoda mul...
Production Capacity: 500sets/month
Delivery Date: within 3 to 5 working days

VAS 5054A VW Audi Skoda multi-language diagnostic tool

VAS 5054A VW Audi Skoda multi-language diagnostic tool
Add Lamborghini and Bentley
Manufacturer Specifications
The VAS 5054A is a universal diagnostic interface for the vehicles of the Volkswagen Group and all OBD vehicle systems from other manufacturers,mainly do AUDI VW Seat.different languages a little different.
With the bluetooth, about 5-10m.
VAS 5054A Software Version:V15/V16/V17/V18
VAS 5054A Language:
English/Germany/Russia/Spanish/Czech/France/Dutch/Greece
Details:
English V18: Basic CD,VW CD, AUDI CD, Skoda CD, Seat CD
Germany V18: Basic CD, VW CD, AUDI CD

Russia V18: Basic CD, VW CD, AUDI CD, Skoda CD
Spanish V18: Basic CD, VW CD, AUDI CD, Skoda CD, Seat CD

Czech V17: Basic CD, VW CD, AUDI CD

France V17: Basic CD, VW CD, AUDI CD

Dutch V17: Basic CD, VW CD, AUDI CD

Greece V17: Basic CD, AUDI CD

English V17: Bentley

English V17: Lamborghini
The following vehicle bus systems are supported:
K line (ISO9141-2)
High-speed CAN (ISO 11898-2)
Low-speed CAN (ISO 11898-3)
J1850 (SAE J1850)

Specification:

The vehicle protocols are handled directly in the VAS 5054A.
This ensures fast response times and a reliable real-time behavior independently of the PC operating system. Every time a connection is established, the VAS 5054A software is identified with the version installed on the application PC. The VAS 5054A thus automatically adopts any new features provided after a new software version has been installed on the application PC.
The diagnostic application and the associated Diagnostic Base System are installed on the application PC.
The diagnostic base system can access the VAS 5054A via Bluetooth or USB.

Access via Bluetooth:After a connection to the VAS 5054A has been set up, the Bluetooth software provides a virtual serial COM port (Bluetooth Serial Port Profile). The Diagnostic Base System uses this COM port to communicate with the VAS 5054A.You need to specify this port when you install the diagnostic application.

Access via USB:You can also connect the VAS 5054A to the application PC by using the supplied USB cable. Windows detects the VAS 5054A through Plug and Play, and automatically installs the drivers copied when you installed the diagnostic application. Setup of the VAS 5054A is then complete and the device is ready for use by the diagnostic application.
Vas 5054A kit includes:
1× VAS 5054A main unit
1×CD(Basis-VASPS 15.00.01-English)
1×CD(Audi-15-84-English)
1×CD(VW-Marke-15-82-GB-English)
1x CD(Operation CD)
1 x CD(Seat-15 English)
When you order it ,pls choose "Free shipping" by hongkong airmail item .
